Little router machine Brushless Dc Motor JSSBY114-4120-CD5 IE 1 48V 500W 12000rpm

Product Categories
Changzhou Jinsanshi Mechatronics Co., Ltd
Contact Now

Little router machine Brushless Dc Motor JSSBY114-4120-CD5 IE 1 48V 500W 12000rpm

  • 1
  • 2
  • 3

Brand Name : JSS

Model Number : JSSBY114-4120-CD5

Certification : CE,ROHS,ISO

Place of Origin : CHINA

MOQ : 1PCS

Price : negotable

Payment Terms : T/T, Western Union，credit card, paypal

Supply Ability : 2000pcs/month

Delivery Time : 1-25days

Packaging Details : cartons

Name : brushless dc motor

Rated Power : 500W

Rated Voltage : 48VDC

Rated Current : 14A

Rated Speed : 12000RPM

Rated Torque : 0.4N.m

Peak Current : 1.2N.m

Body Length : 140mm

collect : ER11

Mass : 1.8kg

size : 57mm

application : router machine

Contact Now

Little router machine Brushless Dc Motor JSSBY114-4120-CD5 IE 1 48V 500W 12000rpm
Product Description

Specification:

Model Rated Voltage(VDC) Rated Current(A) Rated Power(W)

Rated Torque(N.m)

 Peak Torque(N.m)

Rated Speed(rpm)

 Length(mm)
57BLY90-4120 48 12 400 0.3 0.9 12000 120
57BLY110-4120 48 14 500 0.4 1.2 12000 140

57mm Round Shape Brushless DC Motor:

Item Specification
Widing type Star/Delta
Hall effect angle 120 degree electrice angle
Shaft runout 0.025mm
Radial play 0.02mm/50g
End play 0.08mm/50g
IP class IP 40
Dielectric strength 500VDC for one minute
Insulation Resistance 100MΩmin 500VDC

Electrical Connection:

Lead No. Lead color Lead gauge Function Description
1 Yellow UL3266/16AWG PHASE U MOTOR PHASE U
2 Green PHASE V MOTOR PHASE V
3 Blue PHASE W MOTOR PHASE W

Little router machine Brushless Dc Motor JSSBY114-4120-CD5 IE 1 48V 500W 12000rpm
